HTHP Vertical Hanks Dyeing Machinery

HTHP Vertical HANKS Dyeing Machinesare faster growing in the markets. We are manufacturing high temperature vertical yarn dyeing machine with latest .. Read More

HTHP Vertical Hanks Dyeing Machinery

HTHP Vertical HANKS Dyeing Machinesare faster growing in the markets. We are manufacturing high temperature vertical yarn dyeing machine with latest quality and trending desHanks igned, best selling machine on textile company with highly experienced in yarn dyeing machine. Sharman Mechanical Works are manufacturers, suppliers and exporters of vertical yarn dyeing machine with long lasting features and international standards. HTHP vertical yarn dyeing machines have been creating for Fabric and yarn dyeing such as Ribbon, Top, Hank, and Zippers. Our machine is dyeing 10 to 1500kg at a one time.

Features:

1. All machine part approaching into deal with the dye is finished of AISI SS 316L, extremely oxidisation resistance
2. Dual stage turbo pumps for liquor movement (In & Out) with inverter drive for varying speeds
3. MLR of 1:6 (Fully Submerged) 1:5 (Air Pad Systems)
4. Ait pad systems to inserts air manually into the machines to design fixed density and to minimize the ratio
5. Addition tank with injection pump colour for tired the dyeing machine
6. Heat exchangers inbuilt to machine having heat minimize
7. Flexible and variable loading speed
8. Checking and Sampling dyeing machine while operating
9. Human / Machines Security Connects

Optional Feature

1. Several fills
2. Various drains
3. Several heating systems such as electric heater, steams & gas/diesel flame
4. Stock tank with fully capacity & mixing agitator with heating transfer pumps
5. ph meters
6. Hydro extractions systems



Technical Data:

1. Maximum design pressure 6 bar
2. Maximum design temperature 160C
3. Heating gradient 25C - 130C approx. at 5C/min. (Dry saturated steam pressure at 7 bar)
4. Cooling gradient 130C - 85C approx. at 3.5C/min. (Cold water of 25C at 3 bar)
