Toyoda Sulzer Projectile Weaving Machines

Ask Latest Price

Product Specification :

Automatic Grade: Automatic

Max Speed For Stitch: Othe

Condition: Used

Minimum Order Quantity 1 UnitBrandTOYODA SULZERModel Number P7100 W 220 N4 SP D1Condition Second handMachine Type AutomaticFilling Colo...

Adarsh Trading Company

bhiwandi, maharashtra

Related products from this supplier

Nature of Business

supplier, wholesaler

Founded in year 2009 at Bhiwandi. We are a sole proprietorship firm engaged wholesaler and trader a high range and best quality of warping machines,knitted machines,dyeing machinery,spinning machinery,rapier loom,air jet loom,sizing machines,fabrics

Product Specification

Automatic Grade: Automatic

Max Speed For Stitch: Othe

Condition: Used

Minimum Order Quantity 1 Unit
BrandTOYODA SULZER
Model Number P7100 W 220 N4 SP D1
Condition Second hand
Machine Type Automatic
Filling Colour4 COLOUR


Machine Details

P7100 W 220 N4 SP D1

Quantity 1 set

Year 1989

4-Color Weft Insertion, Staubli KR4-2035 Dobby

and each machine with

20 levers in the dobby

18 harness drives

12 heddle frames, type Grobamextra with 330ED with separators

1 automatic and electronic let-off by Sulzer

1 motor type 5kw, 200V, 60Hz

1 back whip roll

1.5 warp beams (940mm flange dia.), 2520mm barrel length

1.5 cloth rollers upto 500mm

1 cloth support

1 pair of short temples

1 set of projectiles, clamping force 2200gm

1 weft package for 4 colors

1 weft brake, double brake

4 MS Feeders for 4-color weaving

4 Loepfe Electronic weft stop motion

4 ROJ HT-Quartz type weft accumulators

5 contact bars for warp stop motion, type symmetric

1 lot of guide teeth, half/half approx. 85% of full width

5000 dropper pins

5000 heddle wires

1 Swiss Sulzer Multi-Card control panel

PU 85 VSD S150 KR D1

Quantity 4 sets

Year 1987

4-Color Weft Insertion, Staubli KR2-2430 Dobby

and each machine with

20 levers in the dobby

18 harness drives

12 heddle frames, type Grobamextra with 330ED with separators

1 mechanical Let off drive

1 back whip roll

1.5 warp beams (940mm flange dia.), 2520mm barrel length

1.5 cloth rollers upto 500mm

1 cloth support

1 pair of short temples

1 set of projectiles, clamping force 2200gm

1 weft package for 4 colors

1 weft brake, double brake

4 MS Feeders for 4-color weaving

4 Loepfe Electronic weft stop motion

4 ROJ HT-Quartz type weft accumulators

6 contact bars for warp stop motion, type symmetric

1 lot of guide teeth, approx. 85% of full width

5000 dropper pins

5000 heddle wires

1 Swiss Sulzer Multi-Card control panel
