Working Width
165cm :: 170cm :: 190cm

Machine Dimension in feet12 * 5'6' :: 12'2' * 5'6' :: 12'8' * 5'6'

Main Deive1.5 kw 6P Electro Magnetic Brake Motor

RPMUpto 250 RPM

Weft Insertion SpeedUpto 450 m/min

Shedding DevicePositive by Tappet Cam

Weft SelectionPick and pick selection by mechanical

Weaving SelectionFilament yarn 20 to 2000 denier

Spun yarn 20 to 120's

Control/brake systemWarp : infrared,

Weft : Piezoelectric sensor

Let offMechanical

Let off beam diaUpto 600 mm

Take upSemi positive - 5 roll

Take up beam diaUpto 400 mm

SelvedgeIndependent Leno selvedge

Selvedge cutterMechanical

TempleRing type cylinder with pin.
